Alpha-Projector

The Alpha Projector is a dynamic 3D laser projection positioning system designed for industrial guidance, assembly assistance, and manufacturing process optimization. It uses advanced optical projection technology and intelligent software to project precise visual instructions directly onto work surfaces, improving accuracy, reducing errors, and enhancing production efficiency in complex industrial environments.

Compare

Add to wishlist

Product successfully added to the Quote List

SKU: ALPHA-PROJECTOR-INSVISION Categories: 3D SCANNERS, 3D Scanning, Digital Fabrication Brand: Invision

Description
About Brand

Description

Alpha-Projector

Dynamic 3D laser projection for guided assembly

CAD Format Import

Import STP, IGES, DXF and DWG; supports FiberSIM/CATIA CPD.

Foreign Object Detection

Locates foreign objects and prompts operators to remove them.

Traceable Reports

Records each job and generates traceable digital reports.

Mobile Control

Operate projection hardware from mobile devices, away from the PC.

Auto Coordinate Alignment

Aligns coordinates in real time and tracks workpiece movement.

Service Support

Warranty-period upgrades and training support stable use.

User Management

Configure roles and permissions; record operator activity.

Custom Functions

SDK and software customization support internal workflows.

Technical Specifications

Technical Specifications	ALPHA-T I	ALPHA-T II	ALPHA-T MAX	ALPHA-T PLUS
Dimensions	Length × Width × Height: 580 × 185 × 170 mm	Length × Width × Height: 580 × 185 × 170 mm	Length × Width × Height: 580 × 185 × 170 mm	Length × Width × Height: 580 × 185 × 170 mm
Weight	9.5 kg	9.5 kg	9.5 kg	9.5 kg
Sensor	Binocular Vision System	Binocular Vision System	High-Precision Binocular Vision System	High-Precision Binocular Vision System
Working Distance	1.3–3.5 m	1.5–8 m (customizable)	1.5–5.5 m	1.5–8 m (customizable)
Projection Accuracy	Maximum 0.38 mm	Maximum 0.5 mm	Maximum 0.25 mm	Maximum 0.25 mm
Maximum Projection Angle	45° × 45°	60° × 60°	60° × 60°	60° × 60°
Beam Focusing	None	Manual focus	None	Automatic focusing
Environmental Conditions	-5 to 40°C, 10–90% relative humidity, no condensation	-5 to 40°C, 10–90% relative humidity, no condensation	-5 to 40°C, 10–90% relative humidity, no condensation	-5 to 40°C, 10–90% relative humidity, no condensation
Laser Class	3R, < 5mW (not safe for direct eye viewing; customizable)	3R, < 5mW (not safe for direct eye viewing; customizable)	3R, < 5mW (not safe for direct eye viewing; customizable)	3R, < 5mW (not safe for direct eye viewing; customizable)
Laser Wavelength	520 nm	520 nm	520 nm	520 nm
Interface	USB 3.0 or Ethernet port	USB 3.0 or Ethernet port	USB 3.0 or Ethernet port	USB 3.0 or Ethernet port
Voltage	220 V	220 V	220 V	220 V
IP Protection Rating	IP54	IP54	IP54	IP54
Supported Data Types	IGES, STP, DXF, DWG — compatible with FiberSIM and CATIA CPD software formats (format customization supported).	IGES, STP, DXF, DWG — compatible with FiberSIM and CATIA CPD software formats (format customization supported).	IGES, STP, DXF, DWG — compatible with FiberSIM and CATIA CPD software formats (format customization supported).	IGES, STP, DXF, DWG — compatible with FiberSIM and CATIA CPD software formats (format customization supported).

Relevant Materials

For a live product demonstration, scanning experience, and consultation with a quote, please contact customer service.

AlphaProjector Product Brochure

Download the complete AlphaProjector product brochure containing technical specifications, features and product information.

Download Brochure

About Brand

Invision

IN-VISION Technologies AG develops DLP-based light engines and optical projection systems used in structured-light applications including resin-based 3D printing, lithography, metrology and medical technologies. The brand supports OEMs and technology developers who need precise, reliable light projection for demanding industrial and research workflows.
